CHIR 98014 - ≥98% , CAS No.556813-39-9

CAS: 556813-39-9 Cat. No.: C276108 Molecular Weight: 486.32 EC Number: 809-307-1

GRADE & PURITY ≥98%

Synonyms

DTXSID90433308 | EX-A3193 | N6-[2-[[4-(2,4-Dichlorophenyl)-5-(1H-imidazol-2-yl)-2-pyrimidinyl]amino]ethyl]-3-nitro-2,6-pyridinediamine | 6-N-[2-[[4-(2,4-dichlorophenyl)-5-(1H-imidazol-2-yl)pyrimidin-2-yl]amino]ethyl]-3-nitropyridine-2,6-diamine | A870135

Storage

Store at -20°C,Desiccated

Shipped In

Ice chest + Ice pads

Overview

Store at -20°C. Store under desiccating conditions. The product can be stored for up to 12 months.

Specifications

Synonyms

DTXSID90433308 | EX-A3193 | N6-[2-[[4-(2, 4-Dichlorophenyl)-5-(1H-imidazol-2-yl)-2-pyrimidinyl]amino]ethyl]-3-nitro-2, 6-pyridinediamine | 6-N-[2-[[4-(2, 4-dichlorophenyl)-5-(1H-imidazol-2-yl)pyrimidin-2-yl]amino]ethyl]-3-nitropyridine-2, 6-diamine | A870135

Specifications & Purity

≥98%

Biochemical and Physiological Mechanisms

Potent, selective ATP-competitive GSK3 inhibitor (IC 50 values are 0.58 and 0.65 nM for GSKα and GSKβ respectively). Potently activates the Wnt/beta-catenin signaling pathway.

Storage

Store at -20°C, Desiccated

Shipped In

Ice chest + Ice pads

This product requires cold chain shipping. Ground and other economy services are not available.

Action Type

INHIBITOR

Note

Wherever possible, you should prepare and use solutions on the same day. However, if you need to make up stock solutions in advance, we recommend that you store the solution as aliquots in tightly sealed vials at -20°C. Generally, these will be useable for up to one month. Before use, and prior to opening the vial we recommend that you allow your product to equilibrate to room temperature for at least 1 hour. Need more advice on solubility, usage and handling? Please visit our frequently asked questions (FAQ) page for more details.

Purity

≥98%

Names and Identifiers

• Pubchem Sid: 504765153
• Pubchem Sid Url: https://pubchem.ncbi.nlm.nih.gov/substance/504765153
• Canonical Smiles: C1=CC(=C(C=C1Cl)Cl)C2=NC(=NC=C2C3=NC=CN3)NCCNC4=NC(=C(C=C4)[N+](=O)[O-])N
• IUPAC Name: 6-N-[2-[[4-(2,4-dichlorophenyl)-5-(1H-imidazol-2-yl)pyrimidin-2-yl]amino]ethyl]-3-nitropyridine-2,6-diamine
• InChIKey: NDFXSHIIGXVOKT-UHFFFAOYSA-N
• INCHI: 1S/C20H17Cl2N9O2/c21-11-1-2-12(14(22)9-11)17-13(19-25-6-7-26-19)10-28-20(30-17)27-8-5-24-16-4-3-15(31(32)33)18(23)29-16/h1-4,6-7,9-10H,5,8H2,(H,25,26)(H3,23,24,29)(H,27,28,30)
• Isomeric SMILES: C1=CC(=C(C=C1Cl)Cl)C2=NC(=NC=C2C3=NC=CN3)NCCNC4=NC(=C(C=C4)[N+](=O)[O-])N
• Molecular Weight: 486.32
• Reaxy-Rn: 11809726
• Reaxys-RN_link_address: https://www.reaxys.com/reaxys/secured/hopinto.do?context=S&query=IDE.XRN=11809726&ln=

Taxonomic Classification

Taxonomy Tree

• Kingdom Organic compounds
  • Superclass Organoheterocyclic compounds
    • Class Diazines
      • Subclass Pyrimidines and pyrimidine derivatives

• Kingdom: Organic compounds
• Superclass: Organoheterocyclic compounds
• Class: Diazines
• Subclass: Pyrimidines and pyrimidine derivatives
• Intermediate Tree Nodes: Not available
• Direct Parent: Phenylpyrimidines
• Alternative Parents: Dichlorobenzenes Nitroaromatic compounds Aminopyridines and derivatives Aminopyrimidines and derivatives Aryl chlorides Imidolactams Imidazoles Heteroaromatic compounds Azacyclic compounds Propargyl-type 1,3-dipolar organic compounds Organic oxoazanium compounds Organic oxides Organic zwitterions Primary amines Hydrocarbon derivatives Organochlorides Organic salts
• Molecular Framework: Aromatic heteromonocyclic compounds
• Substituents: 4-phenylpyrimidine - 1,3-dichlorobenzene - Nitroaromatic compound - Aminopyridine - Aminopyrimidine - Chlorobenzene - Halobenzene - Aryl chloride - Aryl halide - Monocyclic benzene moiety - Pyridine - Benzenoid - Imidolactam - Azole - Heteroaromatic compound - Imidazole - Organic nitro compound - C-nitro compound - Organic 1,3-dipolar compound - Propargyl-type 1,3-dipolar organic compound - Allyl-type 1,3-dipolar organic compound - Azacycle - Organic oxoazanium - Primary amine - Organic nitrogen compound - Amine - Organic oxide - Organic zwitterion - Organic salt - Organic oxygen compound - Organohalogen compound - Hydrocarbon derivative - Organochloride - Organonitrogen compound - Aromatic heteromonocyclic compound
• Description: This compound belongs to the class of organic compounds known as phenylpyrimidines. These are polycyclic aromatic compounds containing a benzene ring linked to a pyrimidine ring through a CC or CN bond. Pyrimidine is a 6-membered ring consisting of four carbon atoms and two nitrogen centers at the 1- and 3- ring positions.
• External Descriptors: Not available

Data sources

1. Djoumbou Feunang Y, Eisner R, Knox C, Chepelev L, Hastings J, Owen G, Fahy E, Steinbeck C, Subramanian S, Bolton E, Greiner R, and Wishart DS. ClassyFire: Automated Chemical Classification With A Comprehensive, Computable Taxonomy. Journal of Cheminformatics, 2016, 8:61.

DOI: 10.1186/s13321-016-0174-y

Associated Targets(Human)

GSK3B Tclin Glycogen synthase kinase-3 beta (3 Activities)

Discover Target: GSK3B

Activity Type	Activity Value -log(M)	Mechanism of Action	Activity Reference	Publications (PubMed IDs)

GSK3A Tclin Glycogen synthase kinase-3 alpha (2 Activities)

Discover Target: GSK3A

Activity Type	Activity Value -log(M)	Mechanism of Action	Activity Reference	Publications (PubMed IDs)

IGF1R Tclin Insulin-like growth factor I receptor (8605 Activities)

Discover Target: IGF1R

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

GSK3B Tclin Glycogen synthase kinase-3 beta (11785 Activities)

Discover Target: GSK3B

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

PRKCZ Tchem Protein kinase C zeta (2414 Activities)

Discover Target: PRKCZ

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

FGFR1 Tclin Fibroblast growth factor receptor 1 (9149 Activities)

Discover Target: FGFR1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

PDPK1 Tchem 3-phosphoinositide dependent protein kinase-1 (3758 Activities)

Discover Target: PDPK1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

CSNK1E Tclin Casein kinase I epsilon (1412 Activities)

Discover Target: CSNK1E

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

FLT1 Tclin Vascular endothelial growth factor receptor 1 (6262 Activities)

Discover Target: FLT1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

KDR Tclin Vascular endothelial growth factor receptor 2 (20924 Activities)

Discover Target: KDR

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

GSK3A Tclin Glycogen synthase kinase-3 alpha (3764 Activities)

Discover Target: GSK3A

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

CDK1 Tchem Cyclin-dependent kinase 1 (3927 Activities)

Discover Target: CDK1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

AKT1 Tchem Serine/threonine-protein kinase AKT (9192 Activities)

Discover Target: AKT1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

TEK Tclin Tyrosine-protein kinase TIE-2 (3348 Activities)

Discover Target: TEK

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

CHEK1 Tchem Serine/threonine-protein kinase Chk1 (6846 Activities)

Discover Target: CHEK1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Liver (3974 Activities)

Explore this target

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Associated Targets(non-human)

Mapk1 MAP kinase ERK2 (650 Activities)

Discover Target: Mapk1

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Mus musculus (284745 Activities)

Explore this target

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Rattus norvegicus (775804 Activities)

Explore this target

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Danio rerio (3092 Activities)

Explore this target

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Plasma (328 Activities)

Explore this target

Activity Type	Relation	Activity value	Units	Action Type	Journal	PubMed Id	doi	Assay Aladdin ID

Mechanisms of Action

Chemical and Physical Properties

• Solubility: Soluble in DMSO to 5 mM
• Molecular Weight: 486.300 g/mol
• XLogP3: 4.200
• Hydrogen Bond Donor Count: 4
• Hydrogen Bond Acceptor Count: 9
• Rotatable Bond Count: 7
• Exact Mass: 485.088 Da
• Monoisotopic Mass: 485.088 Da
• Topological Polar Surface Area: 163.000 Ų
• Heavy Atom Count: 33
• Formal Charge: 0
• Complexity: 645.000
• Isotope Atom Count: 0
• Defined Atom Stereocenter Count: 0
• Undefined Atom Stereocenter Count: 0
• Defined Bond Stereocenter Count: 0
• Undefined Bond Stereocenter Count: 0
• The total count of all stereochemical bonds: 0
• Covalently-Bonded Unit Count: 1
